Name: 20kw Solar System Price 30kw 40kw 50kw 60kw 80kw 100kw Solar Energy Systems 10kw Solar Panel System
Brand: Foshan Mars Solar Technology Co., Ltd.
Availability: InStock

Home Products Off Grid Solar Power System

20kw Solar System Price 30kw 40kw 50kw 60kw 80kw 100kw Solar Energy Systems 10kw Solar Panel System

Product Details:

Contact Now

Detailed Product Description

免费安装服务:	不支持	原产地:	Guangdong, China
品牌:	Mars OR OEM	型号:	M3
用途:	Home	太阳能板类型:	单晶硅
电池类型:	胶体电池	控制器类型:	MPPT, IGBT
安装方式:	地面安装, 屋顶安装, 车棚安装, BIPV安装	负载功率:	10000W
输出电压(伏):	110v/220v/230v/240v	输出频率:	50/60hz
工作时长(小时):	24小时	售前项目设计:	Y
产品名称:	太阳能发电系统	系统类型:	离网太阳能发电
太阳能电池板保修:	10年	蓄电池:	胶体电池
控制器:	MPPT太阳能充电控制器	类型:	离网系统交流
逆变器:	纯正弦波逆变器	颜色:	常规颜色，量大可以协商
保修:	10年	证书:	CE/Rohs

Products Description

Hot Sale Product!! 10KW Solar Power System
Item	Model	Description	Quantity
1	Solar Panel	360W monocrystalline A Grade SUNTECH cells of high efficiency 18%	28pcs
2	PV array combiner	8T-96VMultiple PV strings inputs	1pc
3	solar controller & inverter	10KW96VDC 100A96V MPPT controller	1pc
4	Gel Battery	Capacity:12V/200AH,	16pcs
5	Solar Panel Bracket	Customized for roof or ground	1 set
6	Cables	battery cable with battery termnals PV cable ,terminals, Battery switch	1 set

Roof installation

Ground installation

Parking lot installation

Solar Panel

180W monocrystalline solar panel

A Grade SUNTECH cells of high efficiency 18%

Vmp:17.2V Voc:21.6V Imp:5.8A

Operating temperature:-40℃~+80℃

Size : 1200*540*30mm

25 years life time, CE ROHS approval

Solar Hybrid Inverter

Inverter:300W12VDC 110V/120V/220V/230V/240VAC output, City power charger and generator charger build in 12V20A MPPT controller ,90%-95% charge efficiency. LCD display show the solar power generation data, Overload, overcharge, over-discharge protection USA brand MOSFET material

Gel Battery

Capacity:12V/100AH Deep cycle maintenance-free gel battery Service life:6-8 years, Size:331*173*213mm

Solar Panel Bracket

Slope Rooftop or Flat ground design base on your installation place including complete fittings wind load:55m/s,snow load:1.5kn/m2 Structure: Aluminum alloy ,anti-oxidation treatment

Cables

1)2pcs 16mm2*1M battery cable with battery termnals 2)4mm2 PV cable 50M,25M black 25M red. 3)terminals 4)1P 32A Battery switch

Product packaging

Why Choose Us

Why choose to use the MARS Solar?

Solar energy is now the most environmentally friendly energy source in the world. Using the MARS solar system can reduce your
electricity bill by 90%.
We have 10years experience in solar products,we have exported to more than 100 countries and regions.
We have professional installation team. if necessary,we can send engineer to your country, guide the installation.
We have our own factory, use USA and Japan brand power materials,perfectly for quality control.
We have developed some agent, convenience to provide after sale service to customer

FAQ

Q:Are you factory or trading company?
A:We have 3000 sqm modern factory.with 4 production lines.We have 40 factory workers and 5 of them are quality control and
engineer guys.Welcome to visit our factory.

Q:How long is the lead time of orders?
A:Goods can be ready for shipment within 7-15 working days upon payment.If we have stock material.It only take 1-2days tu send
goods.

Q:What's the warranty of products?
A:Suggest buy all system from our factory, solar panel have 10 years warranty ,other parts
all have 2 years warranty;During the warranty, will ship the free parts for service ,we promise our quality.

Q:Can we get support if we have our owm market position?
A:Please inform us your details market demand we will discuss and propose helpful suggestion for you to find the best solution for
you.

Q:What is your trade Assurance?
A:100% product quality protection.
100% product on time shipment protection.
100% payment protection for your covered amount.

Q:Can I install it myself?
A:We provide installation drawing and user manual for you,guide the installation.If necessary,we can send our engineer come to
country,and guide the installation.

Q:How to calculate the freight?
A:We will calculate according to the specific location and transportation method, you can discuss it in detail with us.

If you have any other questions, please send an inquiry to contact us!
